orbit: 422,000 km from Jupiter diameter: 3630 km mass: 8.93e22 kg
The pronounciation "EE oh" is also acceptable.
Io was a maiden who was loved by Zeus (Jupiter) and transformed into a heifer in a vain attempt to hide her from the jealous Hera.
Discovered by Galileo and Marius in 1610.
In contrast to most of the moons in the outer solar system, Io and Europa may be somewhat similar in bulk composition to the terrestrial planets, primarily composed of molten silicate rock. Recent data from Galileo indicates that Io has a core of iron (perhaps mixed with iron sulfide) with a radius of at least 900 km.
Io's surface is radically different from any other body in the solar system. It came as a very big surprise to the Voyager scientists on the first encounter. They had expected to see impact craters like those on the other terrestrial bodies and from their number per unit area to estimate the age of Io's surface. But there are very few, if any, impact craters on Io. Therefore, surface is very young.
Instead of craters, Voyager 1 found hundreds of volcanic calderas. Some of the volcanoes are active! Striking photos of actual eruptions with plumes 300 km high were sent back by both Voyagers (right) and Galileo (below). This may have been the most important single discovery of the Voyager missions; it was the first real proof that the interiors of other "terrestrial" bodies are actually hot and active. The material erupting from Io's vents appears to be some form of sulfur or sulfur dioxide. The volcanic eruptions change rapidly. In just four months between the arrivals of Voyager 1 and Voyager 2 some of them stopped and others started up. The deposits surrounding the vents also changed visibly.
Recent images taken with NASA's Infrared Telescope Facility on Mauna Kea, Hawaii show a new and very large eruption (right). A large new feature near Ra Patera has also been seen by HST. Images from Galileo also show many changes from the time of Voyager's encounter. These observations confirm that Io's surface is very active indeed.
Io has an amazing variety of terrains: calderas up to several kilometers deep, lakes of molten sulfur (below right), mountains which are apparently NOT volcanoes (left) extensive flows hundreds of kilometers long of some low viscosity fluid (some form of sulfur?), and volcanic vents. Sulfur and its compounds take on a wide range of colors which are responsible for Io's varigated appearance.
Analysis of the Voyager images led scienties to believe that the lava flows on Io's surface were composed mostly of various compounds of molten sulfur. However, subsequent ground-based infra-red studies indicate that they are too hot for liquid sulfur. One current theory is that Io's lavas are molten silicate rock. Recent HST observations indicate that the material may be rich in sodium. Or there may be a variety of different materials in different locations.
Some of the hottest spots on Io may reach temperatures of 700 K (even 900 K has been reported), though the average is much lower, about 130 K. These hot spots are the principal mechanism by which Io looses its heat.
The energy for all this activity probably derives from tidal interactions between Io, Europa, Ganymede and Jupiter. These three moons are locked into resonant orbits such that Io orbits twice for each orbit of Europa which in turn orbits twice for each orbit of Ganymede. Though Io, like Earth's Moon always faces the same side toward its planet, the effects of Europa and Ganymede cause it to wobble a bit. This wobbling stretches and bends Io by as much as 100 meters (a 100 meter tide!) and generates heat the same way a coat hanger heats up when bent back and forth. (Lacking another body to perturb it, the Moon is not heated by Earth in this way.)
Io also cuts across Jupiter's magnetic field lines, generating an electric current. Though small compared to the tidal heating, this current may carry more than 1 trillion watts. It also strips some material away from Io which forms a torus of intense radiation around Jupiter. Particles escaping from this torus are partially responsible for Jupiter's unusually large magnetosphere.
Recent data from Galileo indicate that Io may have its own magnetic field as does Ganymede.
Io has a thin atmosphere composed of sulfur dioxide and perhaps some other gases.
Unlike the other Galilean satellites, Io has little or no water. This is probably because Jupiter was hot enough early in the evolution of the solar system to drive off the volatile elements in the vicinity of Io but not so hot to do so farther out.
